Supports up to 3 independent displays (native display and 2 external monitors via HDMI® and USB-C®) • HDMI® supports up to 3840x2160@30Hz • USB-C® supports up to 4096x2160@60Hz
Chipset
Chipset
Intel® SoC (System on Chip) platform
Memory
Max Memory
8GB soldered memory, not upgradable
12GB soldered memory, not upgradable
16GB soldered memory, not upgradable
Memory Slots**
Memory soldered to systemboard, no slots, single-channel (Intel® i3 models)
Memory soldered to systemboard, no slots, dual-channel (Intel® i5 / i7 models)
Memory Type
DDR4-3200
Storage
Storage Support[1]
Models with 45Wh battery: up to two drives, 1x 2.5" HDD + 1x M.2 SSD • 2.5" HDD up to 1TB • M.2 2242 SSD up to 512GB • M.2 2280 SSD up to 1TB
Models with 57Wh battery: up to two drives, 1x 2.5" HDD + 1x M.2 SSD • 2.5" HDD up to 1TB • M.2 2242 SSD up to 512GB • M.2 2280 SSD up to 1TB
Models with 76Wh battery: one drive, 1x M.2 SSD • M.2 2242 SSD up to 512GB • M.2 2280 SSD up to 1TB
Storage Slot
Models with 45Wh battery: one 2.5" drive slot + one M.2 slot • One 2.5" SATA HDD slot • One M.2 2280 PCIe® 4.0 x4 slot
Models with 57Wh battery: one 2.5" drive slot + one M.2 slot • One 2.5" SATA HDD slot • One M.2 2280 PCIe® 4.0 x4 slot
Models with 76Wh battery: one M.2 slot • One M.2 2280 PCIe® 4.0 x4 slot
Storage Type**
Disk Type
Interface
RPM
Offering
2.5" SATA HDD
SATA 6Gb/s
5.4K
2TB
M.2 2242 SSD
PCIe® NVMe®, PCIe® 3.0 x4
-
256GB / 512GB
M.2 2242 SSD
PCIe® NVMe®, PCIe® 4.0 x4
-
256GB / 512GB
M.2 2280 SSD
PCIe® NVMe®, PCIe® 3.0 x4
-
512GB
M.2 2280 SSD
PCIe® NVMe®, PCIe® 4.0 x4
-
512GB / 1TB
Notes:
1. The storage capacity supported is based on the test results with current Lenovo® storage offerings.
Removable Storage
Card Reader
SD card reader
Multi-Media
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, optimized with Dolby Audio™
Microphone
Dual-microphone array
Camera**
FHD 1080p, with privacy shutter, fixed focus
HD 720p, with privacy shutter, fixed focus
Sensor
Sensors
Hall sensor
Battery
Battery**
Integrated Li-Polymer 45Wh battery
Integrated Li-Polymer 57Wh battery, supports Rapid Charge Boost (get 2 hours of runtime with a 15-minute charge)[1]
Integrated Li-Polymer 76Wh battery, supports Rapid Charge Boost (get 2 hours of runtime with a 15-minute charge)[2]
Max Battery Life[3]
Models with 45Wh battery and integrated graphics: MobileMark® 2018@200nits: 6.5 hr Local video (1080p) playback@150nits: 9.9 hr
Models with 57Wh battery and discrete graphics: MobileMark® 2018@200nits: 7.5 hr Local video (1080p) playback@150nits: 12.2 hr
Models with 57Wh battery and integrated graphics: MobileMark® 2018@200nits: 8.5 hr Local video (1080p) playback@150nits: 12.8 hr
Models with 76Wh battery and discrete graphics: MobileMark® 2018@200nits: 10.1 hr Local video (1080p) playback@150nits: 16 hr
Models with 76Wh battery and integrated graphics: MobileMark® 2018@200nits: 11.2 hr Local video (1080p) playback@150nits: 16.4 hr
Notes:
1, 2. Rapid Charge Boost is only effective in hibernates or fully shutting down the computer.
3. All battery life claims are approximate maximum and based on results using the MobileMark® 2014, MobileMark® 2018, MobileMark® 25, JEITA 2.0, continuous 1080p video playback (with 150nits brightness and default volume level) or Google Power Load Test (PLT) battery-life benchmark tests. Actual battery life will vary depending on many factors such as product configuration and usage, software use, wireless functionality, power management settings, and screen brightness. The maximum capacity of the battery will decrease with time and use.
Power Adapter
Power Adapter**[1]
45W USB-C® (3-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz
65W USB-C® (3-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz
1, 2, 3. IPS (in-plane switching) technology may refer to IPS, PLS, ADS, AHVA, AAS.
Input Device
Keyboard
6-row, multimedia Fn keys, numeric keypad
Keyboard Backlight
LED backlight
Non-backlight
Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 69 x 104 mm (2.72 x 4.09 inches)
Mechanical
Dimensions (WxDxH)[1]
Models
Dimensions
Metal models
356.67 x 233.13 x 16.9 mm (14.04 x 9.18 x 0.67 inches)
Plastic models
356.67 x 233.13 x 17.9 mm (14.04 x 9.18 x 0.70 inches)
Weight[2]
Models
Weight
Plastic models
Starting at 1.77 kg (3.90 lbs)
Metal models
Starting at 1.85 kg (4.08 lbs)
Case Color**
Abyss blue
Cloud grey
Stone blue
Storm grey
Surface Treatment
Aluminium stamping (anodized)
Case Material**
Aluminium (top), PC-ABS (bottom)
Aluminium (top), aluminium (bottom)
Notes:
1. The system dimensions may vary depending on configurations.
2. The system weight is approximate and based on results in Lenovo® lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.
