Lian Li Edge Full Modular Power Supply-80 Plus Platinum-ATX 3.0, 3.1-PCIE 5.1-L-Shape Design for Dual Chamber Case-120mm FDB Fan-Supports up to 4X USB Devices
Lian Li Edge Full Modular Power Supply-80 Plus Platinum-ATX 3.0, 3.1-PCIE 5.1-L-Shape Design for Dual Chamber Case-120mm FDB Fan-Supports up to 4X USB Devices
| Category | Specification Details |
|---|---|
| Model Name | EDGE850 (Black) | EDGE1000 (Black) | EDGE1300 (Black) |
| Model No. | EG0850 | EG1000 | EG1300 |
| Dimensions | (D)182 mm X (W)86 mm X (H)150 mm |
| Form Factor / Type | ATX 3.1 | Fully Modular |
| Certification | 80 PLUS Platinum / Cybenetics Platinum / PPLP Platinum |
| Max. DC Output | 850W | 1000W | 1300W |
| Combined +12V | 849.6W | 996W | 1296W |
| Efficiency | Up to 92.41% Max |
| Cooling | 120mm FDB Fan (2000RPM for 850W | 2400RPM for 1000W/1300W) |
| Protective Circuit | OCP / OVP / OTP / OPP / SCP / UVP / SIP / NLP |
| PCIe Connectors | 850W: 3x (8/6+2 Pin) | 1000W/1300W: 4x (8/6+2 Pin) |
| 12V-2x6 Connector | 1x 550mm (All Models) | 1300W includes additional 12V-2x6 to 2x8pin |
| SATA / Peripheral | 12x SATA Connectors | 4x 4-Pin Peripheral Connectors |
| USB Hub Connectors | Includes USB 9-pin to 9-pin and USB 9-pin to Type-A cables |
| Warranty | 10 Years |
Select Watt
From $141.22
Lian Li Edge Full Modular Power Supply-80 Plus Platinum-ATX 3.0, 3.1-PCIE 5.1-L-Shape Design for Dual Chamber Case-120mm FDB Fan-Supports up to 4X USB Devices—
$141.22
Description
| Category | Specification Details |
|---|---|
| Model Name | EDGE850 (Black) | EDGE1000 (Black) | EDGE1300 (Black) |
| Model No. | EG0850 | EG1000 | EG1300 |
| Dimensions | (D)182 mm X (W)86 mm X (H)150 mm |
| Form Factor / Type | ATX 3.1 | Fully Modular |
| Certification | 80 PLUS Platinum / Cybenetics Platinum / PPLP Platinum |
| Max. DC Output | 850W | 1000W | 1300W |
| Combined +12V | 849.6W | 996W | 1296W |
| Efficiency | Up to 92.41% Max |
| Cooling | 120mm FDB Fan (2000RPM for 850W | 2400RPM for 1000W/1300W) |
| Protective Circuit | OCP / OVP / OTP / OPP / SCP / UVP / SIP / NLP |
| PCIe Connectors | 850W: 3x (8/6+2 Pin) | 1000W/1300W: 4x (8/6+2 Pin) |
| 12V-2x6 Connector | 1x 550mm (All Models) | 1300W includes additional 12V-2x6 to 2x8pin |
| SATA / Peripheral | 12x SATA Connectors | 4x 4-Pin Peripheral Connectors |
| USB Hub Connectors | Includes USB 9-pin to 9-pin and USB 9-pin to Type-A cables |
| Warranty | 10 Years |
