GIGABYTE Radeon RX 6500 XT EAGLE 4G Graphics Card

GIGABYTE Radeon RX 6500 XT EAGLE 4G Graphics Card

ALTERNATE SPINNING

Alternate Spinning can reduce the turbulence of adjacent fans and increase air pressure.

SMOOTH AIRFLOW

GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.

3D ACTIVE FAN

The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.

UNIQUE BLADE FAN

The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.

GRAPHENE NANO LUBRICANT

Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.

ULTRA COOLING

Lower RDS(on) MOSFETs are specially designed to produce lower switching resistance for faster electric current charging and discharging at extremely low temperature.

LOW POWER LOSS

Metal Choke hold energy much longer than common iron-core chokes at high frequency, thus effectively reduce core energy loss and EMI interference.

LONGER LIFE

Lower ESR Solid Capacitors ensure better electronic conductivity for excellent system performance and longer lifespan.

FRIENDLY PCB DESIGN

Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.

• Graphics Processing : Radeon RX 6500 XT

• Core Clock

  Boost Clock* : up to 2815 MHz

  Game Clock* : up to 2610 MHz

• Stream Processors ; 1024

• Process Technology : 6 nm

• Memory Clock ; 18000 MHz

• Memory Size : 4 GB

• Memory Type ; GDDR6

• Memory Bus ; 64 bit

• Memory Bandwidth (GB/sec)N : 144 GB/s

• Card Bus : PCI-E 4.0

• Digital max resolution : 7680x4320

• Multi-view : 2

• Card size : L=192 W=117 H=38 mm

• PCB Form : ATX

• DirectX : 12 Ultimate

• OpenGL : 4.6

• Recommended PSU : 400W

• Power Connectors : 6 pin*1

• Output

  DisplayPort 1.4a *1
  HDMI 2.1 *1

• Accessories : Quick guide
